| Parameter | Specification |
|---|---|
| Dosing Method | Volumetric Rotary Cups / Heavy-Duty Servo Auger Filler |
| Packaging Speed | 25–55 bags/min (Depending on target weight and film materials) |
| Bag Type Capability | Pillow Pouch, Side Gusseted Stand-up Bag, 4-Side Sealed Bag |
| Max Film Width | Max. 420 mm / 520 mm / 720 mm (Configured based on bag specs) |
| Machine Materials | Chemical & Alkaline Resistant SUS304 Stainless Steel |
On this page
Applications and materials
This configuration serves the following products and applications. Our engineers review product behavior and pack requirements with representative samples.
- Daily Chemical & Detergent Factories.
- Household Cleaning Product Wholesalers.
- Contract Chemical Packaging Plants (Co-packers).
Configuration and scope
We develop the equipment configuration, tooling and integration around your product, pack format and production requirements.
Configuration items for engineering review
- Heavy-Duty Volumetric Cup or Servo Auger Dosing System
- Reinforcing Double Servo Film Pulling System
- Dosing Method
Machine features
Review these features with our engineering team to select the configuration for your product and packaging requirements.
- Alkaline-Resistant Food & Chemical Grade SUS304 Build: All contact areas are constructed from reinforced SUS304 stainless steel. This specialized build prevents structural oxidation and corrosion caused by aggressive chemical surfactant agents.
- Reinforcing Double Servo Film Pulling System: Engineered for handling heavy bag weights. Dual servo-driven vacuum transport belts ensure high-precision film alignment without slippage or pouch deformation.
- Hermetically Sealed, Dust-Isolated Electrical Cabinet: Safeguards core PLCs and HMI systems from fine chemical dust. Relocated vents and premium air filtration prevent internal component short-circuiting.
Specifications and conditions
The specifications below describe this configuration with its operating conditions. We review the product, pack format, tooling and utilities for your installation.
| Parameter | Specification | Conditions |
|---|---|---|
| Dosing Method | Volumetric Rotary Cups / Heavy-Duty Servo Auger Filler | Standard configuration; options are listed in the quotation. |
| Packaging Speed | 25–55 bags/min (Depending on target weight and film materials) | Depends on the product, fill weight and pack size. |
| Bag Type Capability | Pillow Pouch, Side Gusseted Stand-up Bag, 4-Side Sealed Bag | Each pack style needs its own tooling. |
| Max Film Width | Max. 420 mm / 520 mm / 720 mm (Configured based on bag specs) | Widest film reel the machine takes. |
| Machine Materials | Chemical & Alkaline Resistant SUS304 Stainless Steel | Frame and product-contact parts. |
How this fits the Vertical Form Fill Seal Machines process
Vertical form-fill-seal machines form bags from roll film around a forming tube, dose the product from above and seal each bag. The dosing unit, bag style and options such as gas flushing or coding define the scope of a configuration.
This machine is part of our Vertical Form Fill Seal Machines portfolio. Explore the configurations for other products and pack formats, or discuss a tailored arrangement with our engineering team.
The linked guides explain how this type of machine works and how to choose one.
Questions buyers ask about this configuration
Short answers to what buyers ask most often when they review a configuration.
How do I get output and dimensions for my product?
Use each specification with its material, format and operating conditions. Our engineers define the output, pack-size range and utilities for your production requirements.
Can I test my product before ordering?
A representative sample test helps resolve material-specific questions before quotation. Please do not ship physical samples until the team has confirmed the quantity needed and where to send them.
Is this the configuration I would receive?
We configure the machine around your product, pack formats and production requirements. Our engineering review defines the model, equipment, options and operating conditions for your project.
What defines the scope of a Vertical Form Fill Seal Machines configuration?
Vertical form-fill-seal machines form bags from roll film around a forming tube, dose the product from above and seal each bag. The dosing unit, bag style and options such as gas flushing or coding define the scope of a configuration.
Engineering support
LINEVO engineers develop machine configurations and packaging-line interfaces around your production task. We bring application review, equipment selection and technical support into one project.
Product and packaging-material trials focus on the functions that matter for your application. Our team helps with configuration, operation, parameter adjustment and maintenance planning.
Review your application
Send the following to discuss this configuration. A representative sample test helps resolve material-specific questions before quotation.
- Product name and form (powder, granule, liquid, paste or solid pieces), with a sample or photos
- Target fill weight or volume, or the item count per pack
- Pack type and dimensions, and the packaging material you use
- Target output per minute or per shift
- Site utilities: voltage, phase and frequency, and compressed air
- Any upstream or downstream equipment the machine must connect to
What to send us
Send what you have and mark what is still undecided. Discuss your application with LINEVO.
| Item | Why we need it | Example format |
|---|---|---|
| Product and its behavior | Powder, granule, liquid, paste or solid pieces decide the dosing method and the parts that touch the product. | Free-flowing granules, with a photo of the product |
| Finished pack and fill | The pack style, its size and the fill per pack set the format and the dosing range. | Pillow bag, 100 × 150 mm, 50 g per bag |
| Target output | Output per minute or per shift decides the number of lanes and the model size. | 60 good packs per minute, one shift per day |
| Packaging material | Film or container type affects sealing, forming and the settings we confirm. | Laminated roll film, 250 mm wide, or the film datasheet |
| Site and destination | Power supply, compressed air and destination country decide the electrical and utility scope. | 380 V, 3-phase, 50 Hz, delivery to Germany |
