| Parameter | Specification |
|---|---|
| Lanes | 2–4 / 3–10 / 4–16 |
| Applicable Material | Ketchup, Tomato Paste, Chili Sauce, Viscous Liquid |
| Bag Type | 4 Sides Sealing Sachet |
| Filling Range | 5–100 ml (Can be extended up to 500 ml) |
| Bag Length | 45–160 mm |
| Bag Width | 50–125 mm |
| Film Width | Max. 500 / 700 / 980 mm |
| Packing Speed | 20–40 cuts/min |
| Voltage | 220 V, 50/60 Hz |
| Power | 4 / 5.5 / 7 kW |
| Machine Weight | 650 / 850 / 1000 kg |
| Machine Dimensions | 1540 × 1375 × 2270 / 1790 × 1445 × 2340 / 1940 × 1600 × 2650 mm |
| Sealing Type | 4-Sided Seal |
| Control System | PLC Control + Touch Screen HMI |
| Machine Material | Food Grade Stainless Steel SUS304 |
| Air Consumption | 0.6–0.8 MPa, 0.35 m³/min |
On this page
Applications and materials
This configuration serves the following products and applications. Our engineers review product behavior and pack requirements with representative samples.
- Sauces & Condiments: Tomato ketchup, BBQ sauce, mayonnaise, mustard, tartar sauce, chili oil, soy sauce, hotpot base paste.
- Daily Cosmetics & Chemicals: Shampoo, hair conditioner, body lotion, liquid soap, laundry detergent, facial cream.
- Pharmaceuticals & Health: Liquid syrup, herbal paste, gel medication, enzyme drinks.
Configuration and scope
We develop the equipment configuration, tooling and integration around your product, pack format and production requirements.
Configuration items for engineering review
- Sealing Type
- Premium 4-Side Sealing Perfection
- High-Precision Piston Dosing Pump
- Intelligent PLC & Touch Screen
- Material Feeding & Mixing
- Volumetric Dosing
Machine features
Review these features with our engineering team to select the configuration for your product and packaging requirements.
- Rotary-Valve Piston Dosing: An anti-drip piston pump meters thick liquids. Our engineers validate fill settings and discharge behavior with the sauce and target volume.
- Intelligent PLC & Touch Screen: Powered by a smart PLC system and responsive touchscreen.
- Photoelectric Eye Tracing System: Highly sensitive optical sensor automatically detects and aligns film color marks, securing precise cutting patterns and uniform sachet dimensions.
Working process
The sequence below outlines the packaging process. We coordinate the stations and their order with the selected equipment and line layout.
- Step 1 — Volumetric Dosing: The piston pump meters the configured fill volume.
- Step 2 — Film Pulling & Sachet Forming: The film roll is pulled downward continuously, and the bag-former shapes it into a dual-layer flat sheet for 4-side alignment.
- Step 3 — Vertical & Horizontal Sealing: Heat-sealing rollers seal the sides and bottom securely, while date-coding printers stamps the batch/expiry details.
- Step 4 — Sauce Filling: The dosing nozzle directs the metered ketchup into the formed sachet.
Specifications and conditions
The specifications below describe this configuration with its operating conditions. We review the product, pack format, tooling and utilities for your installation.
| Parameter | Specification | Conditions |
|---|---|---|
| Lanes | 2–4 / 3–10 / 4–16 | Listed for LV-500SY / LV-700SY / LV-980SY respectively; the number of lanes is selected per project. |
| Applicable Material | Ketchup, Tomato Paste, Chili Sauce, Viscous Liquid | Your product and packaging material are run in the sample trial. |
| Bag Type | 4 Sides Sealing Sachet | Four-side seal for all three models; confirm the pack format in the quotation. |
| Filling Range | 5–100 ml (Can be extended up to 500 ml) | The dose for your product is set and checked in the sample trial. |
| Bag Length | 45–160 mm | Same range for all three models; confirm the forming and cutting configuration in the quotation. |
| Bag Width | 50–125 mm | Same range for all three models; confirm the forming tooling in the quotation. |
| Film Width | Max. 500 / 700 / 980 mm | See table note |
| Packing Speed | 20–40 cuts/min | Machine cycles per minute; each cycle cuts one pack in every lane. |
| Voltage | 220 V, 50/60 Hz | Same for all three models; confirm utilities for your site in the quotation. |
| Power | 4 / 5.5 / 7 kW | See table note |
| Machine Weight | 650 / 850 / 1000 kg | See table note |
| Machine Dimensions | 1540 × 1375 × 2270 / 1790 × 1445 × 2340 / 1940 × 1600 × 2650 mm | See table note |
| Sealing Type | 4-Sided Seal | Each pack style needs its own tooling. |
| Control System | PLC Control + Touch Screen HMI | Standard configuration; options are listed in the quotation. |
| Machine Material | Food Grade Stainless Steel SUS304 | Frame and product-contact parts. |
| Air Consumption | 0.6–0.8 MPa, 0.35 m³/min | Compressed air at the machine. |
Listed for LV-500SY / LV-700SY / LV-980SY respectively; confirm for your product, pack format and utilities in the quotation.
How this fits the Sachet Packing Machines process
Sachet machines form small three- or four-side-sealed packs from roll film and dose each pack, often across several lanes. Sachet size, seal pattern, dosing method and lane count define the scope of a configuration.
This machine is part of our Sachet Packing Machines portfolio. Explore the configurations for other products and pack formats, or discuss a tailored arrangement with our engineering team.
This configuration is also listed on a page that compares the options for the same kind of product or machine.
The linked guides explain how this type of machine works and how to choose one.
Questions buyers ask about this configuration
Short answers to what buyers ask most often when they review a configuration.
How do I get output and dimensions for my product?
Use each specification with its material, format and operating conditions. Our engineers define the output, pack-size range and utilities for your production requirements.
Can I test my product before ordering?
A representative sample test helps resolve material-specific questions before quotation. Please do not ship physical samples until the team has confirmed the quantity needed and where to send them.
Is this the configuration I would receive?
We configure the machine around your product, pack formats and production requirements. Our engineering review defines the model, equipment, options and operating conditions for your project.
What defines the scope of a Sachet Packing Machines configuration?
Sachet machines form small three- or four-side-sealed packs from roll film and dose each pack, often across several lanes. Sachet size, seal pattern, dosing method and lane count define the scope of a configuration.
